15l Station Sta Station Makina Opanga Makina

Model:KGB15L

Zopangidwa kuti zizipanga zochuluka, izi zimayambira makina owumbirawo amapambana popanga zitseko mpaka 15L. Mapangidwe ake osinthika amalola kusaka pakatikati pakati pa kukhazikika kwa mutu umodzi komanso kuwonetsetsa koyenera kwa mitundu yosiyanasiyana ya kukula kwake. Mutha kugula 15L siteshoni imodzi ikuwomba makina owumba kuchokera ku fakitale yathu.

Buku: 15LKulemera: 7.5t

Tumizani Kufunsira

Mafotokozedwe Akatundu Specification Application

Kuchokera ku shampu mabotolo a Jerrycan kuwomba makanema makina owombera, malo amodzi a 15l omwe amawombera makina owumba amapereka magwiridwe antchito apamwamba kwambiri komanso amagwira ntchito mosasintha. Kwezani kuthekera kwanu kupanga ndi makina amphamvu komanso osinthasintha.

Mawonekedwe ndi zabwino

Mutu wamakinawo umatengera njira yodyetsa yomwe imapangidwira 15L, kuwongolera molondola kuchuluka ndi kugawa kwa khoma lakuthwa nthawi zonse, ndikuwonetsetsa kuti muli ndi zotengera zapamwamba kwambiri.
Kudalira pa njira zapamwamba zamagetsi, ngati kuti zopangidwa ndi 15l zikuwomba njira youmba, kugwiritsa ntchito njira, kutengedwa, ndi zinthu zokwanira. Ogwiritsa ntchito amatha kuchita mosavuta malinga ndi momwe zinthu ziliri, kuonetsetsa kuti kupanga kumawona zofunikira zosiyanasiyana pamsika. Itha kubereka zotengera 15l ndi zojambula zosiyanasiyana monga wosanjikiza ndi wosanjikiza, ndipo amathanso kusintha zinthu zapadera kapena zofuna za mafakitale apadera, chakudya ndi minda ina.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB15L
Specification
1	Max container capacity	15L
2	Output(dry Cycle)	450 PC/HR
3	Machine Dimension(L×W×H)	4.5M x2.2 M x2.8 M
4	Machine weight	7.5 T
Clamping Unit
1	Clamping force	165 KN
2	Mold platen size(W×H)	500 MM x 550 MM
3	Platen openingstroke	280 MM - 680 MM
4	Platen moving stroke	600 MM
5	Max mold size(W×H)	580 MM×500 MM
6	Mold thickness	300 MM - 380 MM
Power
1	Servooil pump motor power	18.5KW
2	Servo pump displacement	130 L/MIN
3	Blowpressure	0.6 Mpa
4	Air consumption	0.8 M²/MIN
5	Cooling water pressure	0.2-0.3 Mpa
6	Water consumption	70 L/min
7	Average energy consumption	25 KW-34 KW
Extruder unit
1	Screw diameter	75 MM
2	Screw L/D ratio	25 L/D
3	Melting capacit for HDPE	100 Kg/hr
4	Number of heating zone	4 ZONE
5	Screw heating power	16 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	30 KW
Die head
1	Number of heating sections	3*8 ZONE
2	Heating power	6.5 KW
3	Maxdie-pin diameter	220 MM
4	2Center distance of double die head	240-280MM
5	2MTMax die-pindiameter	150MM
