10l imadziunjikira makina owumba

Model:KGB70A

KGB70A ndi mtundu wosiyanasiyana wa 10l wowonjezera wowumba wopangidwira kwa ma botbort a Max 15-lita kuwomba akuwumba. Monga wopanga zamakina otsogolera amadzi, timapereka njira zosinthira kuti tikwaniritse zofunika zamakasitomala. Makinawo sikuti chifukwa cha mabotolo amadzi, mabotolo ophera tizilombo, ndipo tsiku lililonse amapangira zinthu zopangira, komanso zinthu zazing'ono koma zapadera. Makinawa amakumana ndi zosowa zosiyanasiyana.

Buku: 20lKulemera: 7.8t

Tumizani Kufunsira

Mafotokozedwe Akatundu Specification Application

KGB70A 10L DZIWANI MALO OGULITSIRA MALO OGULITSIRA NDIPONSO KUSINTHA Model, omwe amatengera rod rod yolumikizira yotsatsira, mafuta Cylinder opanikizika mwachindunji chotseka nkhungu, nelinder dirlinder imapha mutu. Hydralic Services Control, Kuthamanga mwachangu ndi kupulumutsa mphamvu.
Zambiri za mawonekedwe apadera azopanga zopanga, angathe Sinthani mawonekedwe ndi makulidwe ambiri.

Mawonekedwe ndi zabwino

Mtunduwu ndi kutseguka kokhazikika ndi kutseka kokhazikika, pogwiritsa ntchito makina omangirira awiri otsetsereka, ndipo cylinder a cylinder opanikizika mwachindunji
● Kufatsa kwa Cylinder Kufa Mutu
● Kuchuluka kwa kuchuluka kwa 20l
● Zoyenera mabotolo amadzi, mathirasiti ophera tizilombo, ndipo tsiku lililonse mankhwala a mankhwala, etc.
● Chochitika chapadera ndikuti limayendetsedwa ndi dongosolo la hydraulic dongosolo kuti mukwaniritse yankho mwachangu komanso mphamvu yayikulu.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
