Makina ozungulira apulasitiki

Model:KGS120Y

Kingg120y ndi pulasitiki yolimba yozungulira makina owumba ogwiritsira ntchito makina owonera a tebulo ozungulira. Pafupipafupi patebulo la pulasitiki kapena panthaka ya pulasitiki youmba zimawononga zofunikira zamakina, zimapereka mapangidwe osinthika komanso apamwamba kwambiri, ndikukupatsani mpikisano.

Buku: 2000LKulemera: 42t

Tumizani Kufunsira

Mafotokozedwe Akatundu Specification Application Workshop

KGS 120y 183 83 Phukusi la Phukusi la Pulate likupanga makina opanga pulasitiki Mtundu wa mtundu, monga piri la gome / lare Makina atha kukhala angwiro kukwaniritsa zofunikira zapadera zopanga zopanga zopanga izi, Ndi ntchito yothamanga kwambiri kuti musunge mtengo.
Imaphatikizapo mooge olamulira 100, mkono waboti, ndi kuwomba pansi kachitidwe, kulimbikitsa zokolola ndi mtundu.

Mawonekedwe ndi zabwino

Amagwiritsidwa ntchito popanga zinthu m'mafakitale osiyanasiyana. Kaya ndi mabotolo ambiri osagwirizana ndi mankhwala, mabotolo a mabotolo okhazikika pamakampani azakudya, kapena mabokosi okhala ndi zopangidwa ndi zinthu zochulukirapo zamankhwala, amatha kuwongoleredwa moyenera kukwaniritsa zofuna kusintha.
Njira yodyetserako zaukadaulo wodula komanso wokhazikika kutengera mawonekedwe apamwamba kwambiri a makina a 120y owuge. Sungani molondola kuchuluka ndi kugawa kwa zinthu zopangira kuti zitsimikizire khoma la mayunitsi la ultra nthawi zambiri, ndikuthetsa zovuta za malonda, ndikuchotsa zofooka zamtunduwu chifukwa cha kudyetsedwa.

Specifications

serial number	Material HDPE…	Mold closing oil cylinder(three cylinders)
serial number	Material HDPE…	Machine model:KGS120Z
Specifications
1	Max container capacity	2000 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	8.3 M ×3.4 M × 6.8 M
4	Machine weight	42 T
Clamping Unit
1	Clamping force	1800 KN
2	Mold platen size(W×H)	1600 MM×1900 MM
3	Platen openingstroke	600 MM-1800 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1650 MM×19000 MM
6	Mold thickness	830MM - 1030 MM
Power
1	Servooil pump motor power	25 KW
2	Servo pump displacement	200 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	2 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	110 KW -130 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	30 L/D
3	Melting capacit for HDPE	350 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	32.5 KW
6	Screw fanpower	0.6 KW
7	Extruder motor power	132 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Maxdie-pin diameter	800(950) MM
4	Accumulator capacity	45(60) L
5	(PE)Accumulator weight	33(45) KG
